4.3.2. Assigning IP addresses (c504, c505 - c516)
The address is assigned according to setting of
c504
(IP mode).
c504
Comments
0
The option uses the address defined in
c505
-
c516
.
1
Don’t use on this product.
2 The option receives its address from DHCP server.
*Setting device name (
c081
-
c096
) is required.
3
The option receives its address from DCP server..
When you setup the IP address by manual (
c504
= 0), inverter needs 4 settings.
 IP address of the inverter (
c505
-
c508
)
 Subnet mask (
c509
-
c512
)
 Gateway address (
c513
-
c516
)
These parameters are effective settings at
c504
= 0 (IP mode: Manual).
If you set a value other than 0 to
c504
, these parameters are invalid.
After dynamic addressing by DHCP server or DCP server, the new address values are displayed in the
parameters
c524
-
c535
.
Case of automatic switching of
c504
(IP mode) to 3 (DCP)
Needed conditions:
- The device has a Station Name (*1) configuration and validation
- The device is connected to a PROFINET controller
- The PROFINET controller has the Station Name (*1) in its own configuration
- The settings are in local configuration of the PROFINET controller
If all of these conditions are fulfilled:
-
c504
(IP mode) is automatically set to 3 (DCP), and
c505
-
c516
are set to 0.
- IP settings are replaced by the one set in local PROFINET controller
- The new configuration is applied immediately
(*1): Depending on the configuration tool you may be referred to as a "device name".
This is different from the device name that is set in the inverter parameters
c081
-
c096
. Station
name will be set / assigned by the configuration tool for PROFINET.
