Toshiba Tosvert VF-S15 Manual

E6582051
- 48 -
6.5.22.
fd06
(Input TB Status) (VF-S15)
bit
TB Name
Function (Parameter)
0
1
0
F
Input terminal function selection 1 (
f111
)
OFF ON
1
R
Input terminal function selection 2 (
f112
)
2
RES
Input terminal function selection 3 (
f113
)
3
S1
Input terminal function selection 4 (
f114
)
4
S2
Input terminal function selection 5 (
f115
)
5
S3
Input terminal function selection 6 (
f116
)
6
VIB*1
Input terminal function selection 7 (
f117
)
7
VIA*1
Input terminal function selection 8 (
f118
)
8 to 15
(Undefined)
-
-
-
Note: The bit described "Undefined" is unstable. Do not use the bit for the judgment.
*1: VIA/ VIB are input terminal function when
f109
is logic input.
*The input terminal function is selected by each parameter.
6.5.23. fd06 (Input TB Status) (VF-AS3)
bit
TB Name
Function (Parameter)
0
1
0
F
f111:
Input terminal function selection 1
OFF ON
1
R
f112:
Input terminal function selection 2
2
RES
f113:
Input terminal function selection 3
3
S1
f114:
Input terminal function selection 4
4
S2
f115:
Input terminal function selection 5
5
S3
f116:
Input terminal function selection 6
6
S4*1
f117:
Input terminal function selection 7
7
S5*2
f118:
Input terminal function selection 8
8
DI11*3
f119:
Input terminal function selection 9
9
DI12*3
f120:
Input terminal function selection 10
10
DI13*3
f121:
Input terminal function selection 11
11
DI14*3
f122:
Input terminal function selection 12
12
DI15*3
f123:
Input terminal function selection 13
13
DI16*3
f124:
Input terminal function selection 14
14 to 15
(Undefined)
-
-
-
Note: The bit described "Undefined" is unstable. Do not use the bit for the judgment.
*1: Only when the contact input has been selected with f147 (Digital/ Pulse train/PG input),
it is an effective value.
*2: Only when the contact input has been selected with f148 (Digital/ Pulse train/PG input),
it is an effective value.
*3: DI11 – DI16 are the terminals of I/O extension.
