5. INSTALLATION PROCEDURE
5.4 Self Test Print
5-9
EO1-13021
H print test (Receipt)
This option let you run H printing test. The printer prints the ‘H’ character in standard pitch
continuously. When H Print Test (Rcpt) is selected, printer prints the following menu. After selection
of the printing side, test print will start. Press the Paper Feed Button to start or stop the test.
** SELECT PRINTING SIDE?
Front Side Only
> 1 Click
Back Side Only
> 2 Click
Double Side > 3 Click
Enter code, then hold Button DOWN at least 1 second to validate.
Press the Paper Feed Button to stop the test.
H Print test
Stop and exit test -> Long Click
Page number
HHHHH H
HHHHH H
HHHHH H
00000008
To Next Page
