2. SPECIFICATIONS
2.3 Receipt Roll
2-3
EO1-13021
2.3 Receipt Roll
Paper type Thermal paper rolled with the print side facing outside
Width (W1) 80 +0.5/ -1.5 mm
Width (W2) 58 +0/ -1.0 mm (With optional 58 mm paper guide)
Outer diameter (D) 80 +0/ -1 mm
Paper thickness (T) 0.062 +/- 0.005 mm
Weight 55 g/m
2
Outer core diameter 21.5 mm
Inner core diameter 12 mm
Recommended thermal paper Only paper rolled onto a core is acceptable, however, the
paper end should not be pasted to the core. TOSHIBA TEC
recommends using the following thermal paper for this
product
Manufacturer : KANZAKI
Type : P-300
CAUTION!
Use only paper which meets specified requirements. Use of non-specified paper may shorten
the head life of the printer, resulting in problems with print quality, cause a paper feed failure or
shorten the cutter life. All paper should be handled with care to avoid any damage to the paper.
Read the following guideline carefully.
• Do not store the paper for longer than the manufacturer’s recommended shelf life.
• Store the paper in a cool, dry place. Avoid areas where they would be exposed to direct sunlight, high
temperature, high humidity, dust or gas.
• A contact of chemical or oil may discolor or erase the printed record.
• Rubbing the paper hard with nail or hard object may discolor the paper.
• The paper end should not be pasted to the core.
For further information please contact your authorized TOSHIBA TEC representative or authorized paper
manufacturer.
W1 or W2
HEAT SENSITIVE SURFACE
ON BOTH SIDES OF PAPER
To Next Page
