Appendix C Related Products
Note 1: In ordering AUI cables, specify the required length.
Use small-diameter cables. Otherwise, the cable connector clamps may not be
usable. The maximum length of usable AUI cables is 15 meters.
Note 2: When you order an RS-232C cable, specify the desired length.
Table C-1 Related Products
Product Model Standard Applicable cord Remarks
3D-2V
(10BASE2 cable)
ZCA123A***1 BNC connector 4Y8B0271P001 For use in bus-A
10BASE2 panel
ZCA133A***1-B BNC connector 4Y8B0271P002 For use in bus-B
10BASE2 panel
5D-2W
(10BASE2 cable)
ZCA125A***1 BNC connector 4Y8B0272P001 For use outside bus-A
10BASE2 panel
ZCA135A***1-B BNC connector 4Y8B0272P002 For use outside bus-B
10BASE2 panel
T-adapter BNC-TA (JPJ) -AU1 BNC connector 5P8C1316P004 Attached to module
connector
Terminator TBP65-AU1 50 ohms 5P8C1316P003 For 10BASE2
Relay connector unit UCNE1 Connector
conversion
3Y8B1619 10BASE2
• Relay from inside to
outside panel
• Relay from indoor to
control room
Connector unit for
grounding
UCNE2 Connector
conversion,
grounding
3Y8B1641 For 10BASE2 cable
grounding
AUI cable AUI15 -[ ]M small-diameter,
molded type
5P4P0032P*** SWCC-made (Note 1)
RS-232C cable GCJ6[ ][ ]*CS
(TYPE-G) (Note 2)
9-pin D-sub 5X8C0003
G*****
***** indicates cable
length (in mm)
Category 5 twisted
pair cable (straight
type)
ZCA101A***1 RJ45 connector - Color : Grey
Category 5 twisted
pair cable (cross
type)
ZCA121A***1 RJ45 connector - Color : Purple
AUI15- [ ] M
Length in meters (Example: 5= 5m)
GCJ6 [ ][ ] *CS
Length in meters (Example: 03= 3m)
