176 Ethernet module User’s Manual
Chapter 7 RAS Information
7
(g) Event trace information
• Record size: 16 bytes (8 words)
• Number of records: 160
• Operation on overflow: Old information is updated. This means that it is
always possible to verify the 160 most recent event
trace records.
• Format: Since this format is for EN311 internal data, it is
binary codes. However, the time is expressed in
BCD.
• Event codes/Detail information: See Table 7-8.
F0
Event code
Detailed information 1
Detailed information 2
Detailed information 3
Detailed information 4
Month Year
Hour Day Time information BCD
Seconds Minute
