218 Ethernet module User’s Manual
Appendix C Error Status Table
C
0BxxH Transmission error • Occurs if the EN311 detects an error and responds.
For more information, see Table C.2 below.
Table C-2 Detailed Information
Error Code Description
Normal
completion
01H
Local station fault 02H The local station is in down mode
Local station
standby
03H Data transmission in standby mode was requested.
Timeout 20H Timeout occurred during TCP open processing or receive
processing, or during UDP receive processing.
Length error 30H Incorrect transmission data length
Station mode
error
40H One of the following requests was issued in a mode other than
standby mode:
a. Parameter setup,b. MAC address setup,c. Reset
MAC/IP not set up 50H Occurs if the MAC address or IP address is not set up.
Transmission
prohibited state
60H • Occurs if a PC link request was issued in run mode in the mes-
sage transmission prohibited state.
• Occurs if a socket open, close, send, or receive request is
issued in run mode in the socket interface transmission prohib-
ited state.
Format error 70H Occurs when there is a format error in the request text.
71H Port number error/IP address error
72H Request code error
73H Time setting: Year 74
H
Time setting: Month
75H Time setting: Day 76
H
Time setting: Hour
77H Time setting: Minute 78
H
Time setting: Second
Opened 80H Occurs if an open request is issued for an already open socket.
Unopened 81H • Occurs if send, receive, or close request is issued for an
unopened socket.
• The TCP socket was used to make the transmit/receive request
to the socket that is receiving CLOSE from the remote station.
Incorrect socket
identifier
82H Occurs if the socket identifier is out of range (1 to 8).
Incorrect control
request
specification
83H Occurs if a request that was prohibited by an operating mode
control request is issued.
• Occurs if a run request is issued in run mode.
• Occurs if a standby request is issued in standby mode.
• Occurs if a run request and a standby request are issued at the
same time.
Table C-1 Contents of Completion Statuses
STATUS Name Explanation
