Tosot TUHD18ND3F1O User Manual

TOSOT DC INVERTER U-MATCH AIR
9
Air Handler
Model
Indoor unit
TUD36A/B-D(U)
TUD48A/B-D(U)
Product Code
EH010N0010
EH010N0020
Outdoor unit
TUHD36ND3F1O
TUHD48ND3F1O
Product Code
CF090W1030
CF090W1070
Capacity
Cooling Capacity
kW
10.00(4.60-12.50)
14.00(3.90-14.60)
Heating Capacity
kW
12.00(4.30-14.70)
15.00(3.80-17.00)
Power Input
Cooling
kW
3.40(0.90-4.00)
5.35(1.20-5.70)
Heating
kW
3.50(0.80-3.80)
5.00(1.10-5.50)
SEER / HSPF
(Btu/h)/W
16.00/9.00
16.00/9.00
Indoor Unit
TUD36A/B-D(U)
TUD48A/B-D(U)
Power Supply
—
208/230V ~60Hz
Fan
Drive
Direct
Direct
Motor Output
kW
0.30×1
0.42×1
Air Flow
m3/h
(CFM)
2000
(1175)
2400
(1410)
Rated Ext. Static Pressure
Pa
(InWg)
37
(0.15)
50
(0.2)
Ext. Static Pressure Range
Pa
(InWg)
0~100
(0-0.4)
0~125
(0-0.5)
Sound Pressure Level(H/M/L)
dB(A)
44/43/41
46/45/43
Air Filter
—
Aluminum
Aluminum
Drain Piping
mm
(inch)
Φ26×3
(Φ1.02×0.12)
Φ26×3
(Φ1.02×0.12)
Outline Dimensions (W×D×H)
mm
(inch)
538×542×1224
(21.2×21.3×48.2)
628×542×1224
(24.7×21.3×48.2)
Net Weight
kg
(lb)
70
(154)
75
(165)
Outdoor Unit
TUHD36ND3F1O
TUHD48ND3F1O
Power Supply
—
208/230V ~60Hz
Heat Exchange
—
Cross Fin Coil
Cross Fin Coil
Compressor
Type
—
Rotary
Rotary
Power Input
W
4580
4580
Refrigerant
Control
—
Electronic Expansion Valve
Electronic Expansion Valve
Charge
kg
(oz)
3.50
(123.48)
4.00
(141.12)
Outline Dimensions (W×H×D)
mm
(inch)
1105×1110×440
(43.5×43.7×17.3)
960×1350×410
(37.8×53.1×16.1)
Net Weight
kg
(lb)
101.0
(223.0)
107.0
(236.0)
Piping Connections
Liquid
Inch
Φ3/8
Φ3/8
Gas
Inch
Φ5/8
Φ5/8
Max. Length
m
(ft)
70
(229.7)
70
(229.7)
Max. Height
m
(ft)
15
(49.2)
15
(49.2)
