Totalcomp TWP Series - Parameter Block

TWP Weighing Indicator Service Manual
- 14 -
PARAMETER BLOCK
Menu
Sub-
Menu
Description
F0 H-L
Weighing
with
set limits
SET Lo
Lower limit value
SET Hi
Upper limit value.
F1 toL
to CLr
Clear the accumulation memory with out printout
to P-C
Print the total accumulation memory and clear the
total memory
to Prt
Print the total accumulation and keep all the memory.
F2 Unt
G
Weighing units
Lb
Oz
Tj
hJ
F3 off
Bl
El on
Display of back light on
El au
Display of back light on automatically
El off
Display of back light off
beep
Bp 1
Beep sound off during the check weighing
Bp 2
Beeper will be sounded with in the check
weighing limits
Bp 3
Beeper will be sounded above the check
weighing limits
P4 prt
RS 232 mode
P prt
By pressing , weighing value will be added to
the memory and print the print out
P cont
Send data continuous
Seire
Also send data continuous
Ask
Bi- direction , through PC
Commands R= Send, T= Tare, Z= Zero
P cnt 2
No documented
P stab
Send data of stable weighing values
P auto
Automatic accumulation.
Individual weighing values are automatically added
Set BAUD rate
After setting the RS 232 mode, display will be shown current
baud rate b XXX. Avail able baud rate: b600, b1200, b2400,
