Toto EcoPower - Rough-In Dimensions

Large Cover
78
ROUGH-IN DIMENSIONS / BOSQUEJO /
ROBINETTERIE BRUTE/DIMENSÕES APROXIMADAS
Left water supply
1” NPT (toilet), 3/4” (urinal)
4-3/4” ± 1/2”
(120 ± 13mm)
Sensor Location
3-7/16” (87mm)
** 11-15/16”
(303mm)
16” (406mm)
3/4” (19mm)
Stud
Toilet top spud
Ø2-3/16” (Ø56mm) hole
Urinal Back spud
Ø1-5/16” (Ø33mm) hole
Toilet Back spud
Ø2-3/16” (Ø56mm) hole
11” (279mm)
CL of sensor
* X”
** 13-1/2”
(343mm)
* 14-3/4” ‡
from top of
Urinal top spud
Ø1-1/2” (Ø38mm) hole
* X”, ‡ = At least 5” clearance from sensor to tip of toilet seat up position or
to top of grab bar is required to avoid false detection.
** Opening in wall
Right water supply
1” NPT (toilet), 3/4” (urinal)
12-5/8” (320mm)
11” (280mm)
14-3/16” (360mm)
12-5/8” (320mm)
11-7/8” (301mm)
11” (280mm)
13-3/8” (340mm)
12-5/8” (320mm)
