A courtyard light (external light e.g. garden lighting) can be connected to the
13
12
court yard light
KL1
terminals 12/13 with 230V and max. 60W ohmic.
court yard light (terminals KL1 12/13) Light / lamps
 OFF
 5–950s adjustable: the courtyard lamp will be triggered for the adjusted time with each opening command.
 10s afterglow: after reaching the open position the coutyard lamp is glowing for 10 seconds.
a signal lamp can be connected to the terminals 10/11 with 24V a.c., max. 5W
KL1
11
10
signal lamp
prewarning OPEN (terminals KL1 10/11) Light / lamps
 OFF
 1–30s adjustable: Before each opening movement the signal lamp/ ashing light is activated for the adjusted time.
prewarning CLOSE (terminals KL1 10/11) Light / lamps
 OFF
 1–30s adjustable: Before each closing movement the signal lamp/ ashing light is activated for the adjusted time.
Light / lamps Connections and adjustments
green phase  20s (factory setting) Light / lamps
 5–120s adjustable [increment 1]: duration of green phase.
clearance time  5s (factory setting) Light / lamps
 1–60s adjustable [increment 1]: time to leave the tra󰀩c light intermediate area.
tra󰀩c light gate CLOSE Light / lamps
 red light OFF: red tra󰀩c light does not illuminate in closed position.
 permanent RED: red tra󰀩c light illuminates also in closed position.
tra󰀩c light logic Light / lamps
 green on both sides: both tra󰀩c lights illuminate GREEN in open position, regardless of which side has been given
the green request.
 green on one side: only the tra󰀩c light illuminates GREEN in open position, from the side from where the green
request has been requested.
Danger
• Before connection works or taking o󰀨 the housing cover the power supply has to be turned o󰀨 !
• Follow safety instructions! (

page 5)
