tousek ST 63 - Menu Structure: Core Settings; Buttons and Switches Configuration; Photocell Function Settings; Safety Edge Configuration

tousek / EN_ST-63_02 / 25. 03. 2020 - 13 -
main layer sub layer settings/adjustments
buttons/switches

page 15
impulse button
 OPEN/STOP/CLOSE
 OPEN/CLOSE/OPEN
 OPEN
 DEADMAN
*) if impulse button is set on
DEADMAN, then all other buttons
also in DEADMAN mode-.
pedestr. opening
 OPEN/STOP/CLOSE
 OPEN/CLOSE/OPEN
 OPEN
 DEADMAN *)
ILD channel
(ILD = Induction loop detector)
 impulse OPEN
 security
 attendence
(also in DEADMAN mode)
 security
 attendence
photocells

page 17
G
inner photocell
 not active
 during closing reverse
 stop, opens after release
 during opening stop-then open
G
outer photocell
 not active
 during closing reverse
 stop, opens after release
G
back area photoc.
 active
 not active
ILD/PHC pause time
ILD/PHC = induction loop detektor / photocell
 no inuence of photocell/ ILD
 cancel pause time (close immediately)
 re-start pause time
 immediate closing after opening
PHC-self test
(PHC = photocell)
 active
 not active
safety edge

page 20
G
safety edge LL1
LL = left leaf
 not active
 opening active
 closing active
 opening / closing
G
safety edge LL2
 not active
 opening active
 closing active
 opening / closing
G
safety edge RL1
RF = right leaf
 not active
 opening active
 closing active
 opening / closing
G
safety edge RL2
 not active
 opening active
 closing active
 opening / closing
SE- status display
 Display: status safety edges (= SE)
left leaf

page 21
delay left leaf
 opening delay
 closing delay
delay time left leaf
 OFF, 1...25s  = 2s
force
 60...100%  = 70%
speed
 60...100% (SWING X3 TPspeed)  = 100%
75...100% (SWING X4 LHTP)
only with
swing gates
soft speed
 25...50%  = 50%
soft stop time OPEN
OFF, 0,1...9,0s  = 5s
soft stop time CLOSE
OFF, 0,1...9,0s  = 5s
right leaf

page 21
delay right leaf
 opening delay
 closing delay
delay time right leaf
 OFF, 1...25s  = 2s
force
 60...100%  = 70%
speed
 60...100% (SWING X3 TPspeed)  = 100%
75...100% (SWING X4 LHTP)
only with
swing gates
soft speed
 25...50%  = 50%
soft stop time OPEN
OFF, 0,1...9,0s  = 5s
soft stop time CLOSE
OFF, 0,1...9,0s  = 5s
operating mode

page 22
impulse logic
 stop, start of pause time
 impulse suppressioning when opening
 pause time extension
G
operating mode
 impulse mode
 1...255s automatic close [ increment 1 ]
pedestr. opening
 25...100%  = 100%
automatic mode
 complete / pedestrian opening
 only complete opening
 only pedestrian opening
pause time logic
 no inuence
 permanent ON
only with
folding gates
ramp time open
1,0...6,0s  = 3s
ramp time close
1,0...6,0s  = 3s
menu item showed:
with tra󰀩c mode, without tra󰀩c mode, with swing gates, with folding gates
swing / folding gate control ST63
+
–
Menu structure Adjustments - overview
ESC ENTER
Note: Some changes in the functionality or operating logic are not accepted until the gate is closed and the word „Ready“ appears on the display.
