031H2−03
−SERVICE SPECIFICATIONS ENGINE MECHANICAL
03−7
1CD−FTV ENGINE REPAIR MANUAL (RM1046E)
TORQUE SPECIFICATION
Part Tightened N×m kgf×cm ft×lbf
Cylinder block water drain cock x Cylinder block 29 291 21
Oil check valve x Cylinder block 33 331 24
Engine rear oil seal retainer x Cylinder block 7.4 75 65 in.×lbf
Oil pump x Cylinder block 31 320 23
Oil pan x Cylinder block (See page 14−4) Bolt A
Bolt B
Bolt C
Nut D
42
21
11
11
428
209
112
112
31
15
8
8
Oil strainer x Oil pan sub−assy Bolt
Nut
21
13
209
135
15
10
Oil pan No.2 x Oil pan sub−assy 12 119 9.0
Cylinder head x Cylinder block 1st
2nd
3rd
4th
45
Turn 90˚
Turn 90˚
Turn 90˚
459
Turn 90˚
Turn 90˚
Turn 90˚
33
Turn 90˚
Turn 90˚
Turn 90˚
Camshaft bearing cap x Cylinder head 20 204 15
Water pump x Cylinder block 31 320 23
Camshaft oil seal retainer x Cylinder head 9.8 100 7.2
Timing belt idler Sub assy No.2 x Oil pump 47 475 34
Timing belt idler No. 1 x Cylinder head 35 357 26
Camshaft timing pulley x Camshaft 88 899 65
Exhaust fuel addition injector x Cylinder head 12 117 8.5
Nozzle holder clamp x Cylinder head 26 265 19
Nozzle leakage pipe x Cylinder head Hollow screw
Flange bolt
16
20
163
204
12
15
Over flow screw x Plug 9.8 100 7.0
Check valve x Cylinder head 21 214 15
Cylinder head cover x Cylinder head 13 135 9.7
Taper screw plug No.1 x Cylinder head 25 255 18
Cylinder head stud bolt (See Page 14−27) Bolt A
Bolt B
Bolt C
Bolt D
Bolt E
8.8
12
28
8.8
8.8
90
120
286
90
90
78 in.×lbf
8.7
21
78 in.×lbf
78 in.×lbf
Connecting rod cap x Connecting rod 1st
2nd
30
Turn 90_
306
Turn 90_
22
Turn 90_
Crankshaft bearing cap x Cylinder block 115 1,173 85
Cylinder block stud bolt 2.9 30 27 in.×lbf
Cylinder block oil orifice x Cylinder block 9.0 92 80 in.×lbf
Oil nozzle No.1 x Cylinder block 7.4 75 65 in.×lbf
