031E7−05
03−10
−SERVICE SPECIFICATIONS STARTING & CHARGING
1CD−FTV ENGINE REPAIR MANUAL (RM1046E)
TORQUE SPECIFICATION
Part Tightened
N×m kgf×cm ft×lbf
Starter commutator end frame assy x Starter brush holder assy 3.8 39 33 in.×lbf
Starter drive housing assy x Starter commutator end frame assy 6.0 61 53 in.×lbf
Magnetic switch x Starter drive housing assy 2.3 23 20 in.×lbf
Magnetic switch x Lead wire 5.9 60 52 in.×lbf
Generator drive end frame assy x Retainer plate 2.3 23 20 in.×lbf
Generator coil assy x Generator drive end frame assy 5.8 59 51 in.×lbf
Generator brush holder assy x Generator coil assy 1.8 18 16 in.×lbf
Generator rear end cover x Generator coil assy 4.6 47 41 in.×lbf
Generator w/clutch pulley x Generator rotor assy 111 1,132 82
