7-817 DISPLAY
7.2.3.2 ANALYZER SCREEN MENU LIST
Analyzer menu screen
Display item Description
Menu screen Screen No.
1. DIAG MEMORY 1. to 10. Indications of errors occurred
2. I/O ENGINE CTRL
(Engine control)
(4Y)
1/10
IGSW Key switch (IG)
STA Key switch (ST)
BATT Battery voltage
G/LP Fuel changeover switch
SEL Fuel specification discrimination signal
ADJ Engine specification discrimination signal
2/10
MREL EFI main relay drive signal
FC Circuit opening relay drive signal
LPR LP gas main relay drive signal
LFC LP gas slow solenoid drive signal
OXHT O2 sensor heater drive signal
3/10
THA Intake temperature sensor voltage
THA( ) Intake air temperature
THW Coolant temperature sensor voltage
THW( ) Coolant temperature
PIM Intake pipe negative pressure sensor voltage
PIM( ) Intake manifold pressure
4/10
VPA1 Accelerator pedal position sensor (1) voltage
VPA1( ) (standard)
VPA2 Accelerator pedal position sensor (2) voltage
VPA2( ) (standard)
PA Throttle position
5/10
VTA1 Throttle position sensor (1) voltage
VTA1( ) (standard)
VTA2 Throttle position sensor (2) voltage
VTA2( ) (standard)
TA Throttle opening angle
IM Electronic throttle motor current
6/10
PA Accelerator pedal position
NE Engine speed
NE( ) (Traveling speed)
TA Throttle position
7/10
NE Engine speed
NE( ) (Traveling speed)
PIM Intake manifold pressure
IGT Ignition timing (spark advance amount)
8/10
NE Engine speed
NE( ) (Traveling speed)
PIM Intake manifold pressure
INJ Injector correction value (gasoline)
OX O2 sensor voltage
7
