Toyota 8FGU15 Repair Manual

5-46 5 OIL CONTROL VALVE
NOTICE
Clean each part thoroughly, remove dirt with compressed air, and apply hydraulic oil before reassembly.
5.2.4.1 Point Operations
Point 2 Disassembly:
Put match marks to prevent solenoid installation in an
incorrect position.
Reassembly:
Align match marks for reassembly.
Inspection:
Check the lift lock solenoid for continuity.
(Reference)
Resistance: 9.4 to 10.4 Ω (at 20 °C)
Inspection:
Check and clean any clogged filter.
Reassembly:
Carefully reassemble to prevent incorrect installation
of each solenoid spool, etc.

Toyota 8FGU15 Specifications

General

Model	8FGU15
Category	Forklifts
Engine Type	Internal Combustion
Load Capacity	3000 lbs
Lift Height	189 inches
Tire Type	Pneumatic
Engine	Toyota 4Y
Power Source	Gasoline
