Toyota 8FGU32 User Manual

0-3
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
E
VEHICLE MODEL
*: USA and CANADA Only
FRAME NUMBER
Frame No. Punching Position
*: EEC spec.
Series Load Capacity Vehicle Model Transmission Type Engine
1 ton series
3000 lbs 8FGCU15 T/C 4Y Gasoline
3500 lbs 8FGCU18 T/C 4Y Gasoline
4000 lbs *8FGCSU20 T/C 4Y Gasoline
Series Engine Vehicle model Punching format
1 ton series 4Y
8FGCU15
8FGCSU20 - 10011
*8FGCSU20 - 10011
8FGCU18
8FGCSU20
Punching position
General
Section 0
0-4a
8FGCU15,18,SU20
Cu1 ton series
Cu1 ton series

Toyota 8FGU32 Specifications

General

Model	8FGU32
Tire Type	Pneumatic
Load Capacity	3200 kg
Fuel Type	Gasoline/LPG
Overall Width	1270 mm (50 in)
Travel Speed (Loaded/Unloaded)	11.8 mph
Lift Speed (Loaded/Unloaded)	0.48 / 0.52 m/s (94.5 / 102.4 fpm)
