457
9-1. Specifications
COASTER_GW-E
9
Vehicle specifications
1HZ engine
*
1
: Vehicles with a cooler system
*
2
: For vehicles with model code*
3
that has “V” as the last letter
*
3
: The model code is indicated on the manufacturer’s label or the Certifica-
tion Regulation label. (P. 453)
Model 1HZ
Type 6 cylinder in line, 4 cycle, diesel
Bore and stroke 94.0 100.0 mm (3.70 3.94 in.)
Displacement 4164 cm
3
(254.0 cu. in.)
Valve clearance
(engine cold)
Intake: 0.15 0.25 mm (0.006 0.010 in.)
Exhaust: 0.35 0.45 mm (0.014 0.018 in.)
Drive belt tension
8 11 mm (0.31 0.43 in.)
11 13 mm (0.43 0.51 in.)
*
1
Drive belt deflection with 98 N (10 kgf, 22 lbf)
thumb force (used belt)
Maximum vehicle
speed
*
2
130 km/h (81 mph)
Maximum torque
(NET)
*
2
285 N•m (29 kgf•m, 210 ft•lbf) @ 2200 rpm
Maximum output
(NET)
*
2
96 kW (129 HP) @ 3800 rpm
1
2
Air
conditioning
compressor
Generator
Fan
Idler
Crankshaft
COASTER_OM_General_OM36742W
To Next Page
