12
Sewing preparations
2. Taking out the bobbin
Before taking out or setting the bobbin case, remove the power plug from the outlet.
Not doing so could cause an injury.
1. Turn the handwheel to move the needle to the
highest position. Always turn the handwheel
towards yourself. (in the direction of the arrow)
2. Hold the left edge of the extension table and
pull out to the left. (in the direction of the arrow)
Open the shuttle cover.
(Open out in the direction of the arrow.)
Pull up the latch of the bobbin case, and use it to
pull out the case.
Take out the bobbin from the bobbin case.
To Next Page
