Toyota ESM21 - Winding the Lower Thread

13
Sewing preparations
3. Winding the lower thread
Before taking out or setting the bobbin case, remove the power plug from the outlet.
Not doing so could cause an injury.
Do not touch the lower thread winding spindle when winding the lower thread.
Not doing so could cause an injury.
Attention
Use a TOYOTA-exclusive bobbin.
Remove the sticker. Pull up
the spool pin from the sewing
machine.
1. Turn the pin around and
insert.
2. Insert the thread spool.
Support the thread on the
sewing machine with one
hand, using the other hand
pass the thread around the
thread guide as shown in
the diagram.
