16
Sewing preparations
5. Threading the upper thread
Before threading the upper thread, remove the power plug from the outlet.
Not doing so could cause an injury.
Raise the presser foot lever.
Note: If the presser foot lever is not raised, the
thread cannot be set correctly.
Pull out the spool pin from the main unit.
1. Turn the spool pin over and insert.
2. Insert the thread spool.
