15
Sewing preparations
4. Threading the lower thread
Before setting the bobbin case, remove the power plug from the outlet.
Not doing so could cause an injury.
Attention
Use a TOYOTA-exclusive bobbin.
Take out the bobbin case.
(refer to P.12 [Taking out the
bobbin])
The thread must flow off the bobbin in the direction
of the arrow, and then insert the bobbin into the
bobbin case.
Hold the end of the thread in your right hand and
pass it through the groove in the bobbin case.
(Pass the thread from 1 to 2)
Press the bobbin with the finger of your left hand,
and then pass the thread through the tension spring
as shown in the diagram.
(Pull until there is a locking sound.)
Turn the handwheel to move the needle to the
highest position.
Always turn the handwheel towards yourself.
Holding the latch of the bobbin case, insert the
bobbin case into the shuttle race.
The bobbin case finger must slot into the groove.
To Next Page
