TP-Link AP500 User Manual

28
Chapter 5
4 ) Select the Enable this Entry checkbox.
5 ) Click OK.
¾ To modify or delete a device from the Blacklist or Whitelist
In the Blacklist or Whitelist, click the modify icon or the delete icon that
corresponds to the device that you wish to modify or delete.
¾ To delete multiple devices from the Blacklist or Whitelist
In the Blacklist or Whitelist, select the corresponding checkboxes of the devices to
be deleted and click Delete above the table.
5. 4. Advanced Wireless Settings
It is recommended to keep the default settings of the advanced wireless settings. If it is
necessary to change them, please perform the following steps.
1. Visit http://tplinkwifi.net, and log in with the username and password you set for the
AP device.
2. Go to Advanced > Wireless > Advanced Settings.

TP-Link AP500 Specifications

General

2.4 GHz	Yes
Frequency band	2.4 - 5 GHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	11g 54M: -76dBm@10% PER 11n HT20 MCS7: -73dBm@10% PER 11n HT40 MCS7: -71dBm@10% PER 11a 6Mbps:-94dBm@10% PER 11a 54Mbps: -75dBm@10% PER 11ac HT20 MCS8: -66dBm@10% PER 11ac HT40 MCS9: -62dBm@10% PER 11ac HT80 MCS9: -59dBm@10% PER
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1300 Mbit/s
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Internal	No
Placement	Table
Certification	CE, FCC, RoHS
Product color	Black
LED indicators	Power, WPS
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Processor frequency	1000 MHz
Compatible operating systems	Microsoft Windows 98SE / NT / 2000 / XP / Vista / 7 / 8 / 8.1, Mac OS, NetWare, UNIX, Linux
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Detachable antenna
Antennas quantity	3
Package type	Box

Weight and Dimensions

Depth	162 mm
Width	242 mm
Height	44 mm
