TP-Link Archer MR400 User Manual

51
Chapter 11
Specify Your Network Settings
• Mode - Select the desired mode.
• 802.11n only - Select only if all of your wireless clients are 802.11n devices.
• 802.11gn mixed - Select if you are using both 802.11g and 802.11n wireless
clients.
• 802.11bgn mixed - Select if you are using a mix of 802.11b, 11g, and 11n
wireless clients.
Note:
When 802.11n only mode is selected, only 802.11n wireless stations can connect to the router. It is strongly
recommended that you select 802.11bgn mixed, and all of 802.11b, 802.11g, and 802.11n wireless clients can
connect to the router.
• 802.11ac/n mixed (5GHz) - Select if you are using both 802.11ac and 802.11n
wireless clients.
• 802.11a/n/ac mixed (5GHz) - Select if you are using a mix of 802.11a, 802.11n
and 802.11ac wireless clients. It is strongly recommended that you select
11a/n/ac mixed.
• Channel - Select the channel you want to use from the drop-down list. This field
determines which operating frequency will be used. It is not necessary to change
the wireless channel unless you notice interference problems with another nearby
access point.
• Channel Width - Select the channel width from the drop-down list. The default setting
is Automatic, which can adjust the channel width for your clients automatically.
¾ To change the security option:
1. Go to Advanced > Wireless > Wireless Settings page.
2. Select the wireless network 2.4GHz or 5GHz.
3. Select an option from the Security drop-down list. The router provides four options,
None, WPA/WPA2 Personal (Recommended), WPA/WPA2 Enterprise, WEP. WPA2
uses the newest standard and the security level is the highest. We recommend you
don’t change the default settings unless necessary.
11. 5. 2. Use WPS for Wireless Connection
You can use WPS feature to add a new wireless device to your existing network quickly.

TP-Link Archer MR400 Specifications

General

VPN server	PPTP VPN, IPSec VPN , OpenVPN
VPN support	PPTP, L2TP, IPSec
Ethernet LAN	Yes
Frequency range	2.4 - 5 GHz
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	5GHz: 11a 54M: -74dBm 11ac HT20: -67dBm 11ac HT40: -64dBm 11ac HT80 : -60dBm 11n HT20: -71dBm 11n HT40: -70dBm 2.4G: 11g 54M: -76dBm 11n HT20: -73dBm 11n HT40: -67dBm
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
USB port	No
Ethernet LAN (RJ-45) ports	3
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, Status, WLAN
Antenna type	Internal & external
Transmit power	CE: \u003C20dBm(2.4GHz), \u003C23dBm(5GHz) dBmW
Antennas quantity	5
Transmit power range	20 - 23 dBmW
Output current	1.5 A
Output voltage	12 V
Power source type	DC
Firewall security	Denial-of-Service (DoS) protection, Stateful packet inspection (SPI) firewall
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
4G standard	LTE
2G standards	EDGE, GPRS, GSM
3G standards	DC-HSPA+, HSPA, HSPA+, UMTS
SIM card type	MicroSIM
4G bands supported	800, 900, 1800, 2100, 2600 MHz
GSM bands supported	850, 900, 1800, 1900 MHz
UMTS bands supported	900, 2100 MHz
Supported network protocols	IPv4, IPv6
Certification	CE, RoHS
Windows operating systems supported	Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Package type	Box
Package depth	223 mm
Package width	307 mm
Package height	70 mm
Package weight	670 g
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
WLAN data transfer rate (first band)	450 Mbit/s
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	141 mm
Width	202 mm
Height	33.6 mm
