TP-Link Archer MR400 User Manual

4
Chapter 1
Get to Know Your 4G LTE Router
The router’s LEDs (view from left to right) are located on the front panel. You can check
the router’s working status by following the LED Explanation table.
LED Explanation
Name Status Indication
(Power)
On Power is on..
Off Power is off.
(Internet)
On The router is connected to the internet.
Off There is no internet connection.
(4G)
On The router is connected to the 4G network.
Off The router is disconnected from the 4G network.
(Wireless)
On At least one wireless radio band (2.4 GHz or 5 GHz) is enabled.
Off The wireless radio band is disabled.
(LAN)
On At least one LAN port is connected to a powered-on device.
Off No LAN port is connected to a powered-on device.
(WPS)
On/ Off
The light remains on for 5 minutes when a WPS connection is
established, then turns off.
Flashing WPS connection is in progress. This may take up to 2 minutes.
(Signal Strength)
On
Indicates the signal strength the router received from the mobile
internet. More lit bars indicates a better signal strength
.
Off There is no mobile internet signal.
Note:
1. If the Internet LED is off, please check your internet connection first. Refer to Connect Your
4G LTE Router for more information about how to make internet connection correctly. If you
have already made a right connection, please contact your ISP to make sure your internet
service is available now.
2. If the Signal Strength LED is off, please check your Internet LED first. If your Internet LED
is also off, please refer to Note 1. If your Internet LED is on, please relocate the router to a
location that receives a strong mobile internet signal, such as near a window.

TP-Link Archer MR400 Specifications

General

VPN server	PPTP VPN, IPSec VPN , OpenVPN
VPN support	PPTP, L2TP, IPSec
Ethernet LAN	Yes
Frequency range	2.4 - 5 GHz
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	5GHz: 11a 54M: -74dBm 11ac HT20: -67dBm 11ac HT40: -64dBm 11ac HT80 : -60dBm 11n HT20: -71dBm 11n HT40: -70dBm 2.4G: 11g 54M: -76dBm 11n HT20: -73dBm 11n HT40: -67dBm
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
USB port	No
Ethernet LAN (RJ-45) ports	3
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, Status, WLAN
Antenna type	Internal & external
Transmit power	CE: \u003C20dBm(2.4GHz), \u003C23dBm(5GHz) dBmW
Antennas quantity	5
Transmit power range	20 - 23 dBmW
Output current	1.5 A
Output voltage	12 V
Power source type	DC
Firewall security	Denial-of-Service (DoS) protection, Stateful packet inspection (SPI) firewall
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
4G standard	LTE
2G standards	EDGE, GPRS, GSM
3G standards	DC-HSPA+, HSPA, HSPA+, UMTS
SIM card type	MicroSIM
4G bands supported	800, 900, 1800, 2100, 2600 MHz
GSM bands supported	850, 900, 1800, 1900 MHz
UMTS bands supported	900, 2100 MHz
Supported network protocols	IPv4, IPv6
Certification	CE, RoHS
Windows operating systems supported	Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Package type	Box
Package depth	223 mm
Package width	307 mm
Package height	70 mm
Package weight	670 g
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
WLAN data transfer rate (first band)	450 Mbit/s
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	141 mm
Width	202 mm
Height	33.6 mm
