TP-Link Archer MR400 User Manual

53
Chapter 11
Specify Your Network Settings
Method 3 Enter the router’s PIN on your client device
Use this method if your client device asks for the router’s PIN.
1. Visit http://tplinkmodem.net, and log in with the password you set for the router.
2. Go to Advanced > Wireless > WPS page. Select the wireless network 2.4GHz or
5GHz according to your wireless client.
3. Keep the Router’s PIN status as enabled. Take a note of the Current PIN of the router.
You can also click the Generate button to get a new PIN.
4. On the client device, enter the router’s PIN. (The default PIN is also labeled on the
bottom of the router.)
5. The WPS LED flashes for about two minutes during the WPS process.
6. When the WPS LED is on, the client device has successfully connected to the router.
Note:
1. The WPS LED on the router will light on for no more than five minutes if the device has been successfully added to
the network.
2. The WPS function cannot be configured if the wireless function of the router is disabled. Please make sure the
wireless function is enabled before configuring the WPS.
11. 5. 3. Schedule Your Wireless Function
You can automatically turn off your wireless network (both 2.4GHz and 5GHz) at time
when you do not need the wireless connection.
1. Visit http://tplinkmodem.net, and log in with the password you set for the router.
2. Go to Advanced > Wireless > Wireless Schedule page.
3. Toggle on the button to enable the Wireless Schedule feature.

TP-Link Archer MR400 Specifications

General

VPN server	PPTP VPN, IPSec VPN , OpenVPN
VPN support	PPTP, L2TP, IPSec
Ethernet LAN	Yes
Frequency range	2.4 - 5 GHz
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	5GHz: 11a 54M: -74dBm 11ac HT20: -67dBm 11ac HT40: -64dBm 11ac HT80 : -60dBm 11n HT20: -71dBm 11n HT40: -70dBm 2.4G: 11g 54M: -76dBm 11n HT20: -73dBm 11n HT40: -67dBm
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
USB port	No
Ethernet LAN (RJ-45) ports	3
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, Status, WLAN
Antenna type	Internal & external
Transmit power	CE: \u003C20dBm(2.4GHz), \u003C23dBm(5GHz) dBmW
Antennas quantity	5
Transmit power range	20 - 23 dBmW
Output current	1.5 A
Output voltage	12 V
Power source type	DC
Firewall security	Denial-of-Service (DoS) protection, Stateful packet inspection (SPI) firewall
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
4G standard	LTE
2G standards	EDGE, GPRS, GSM
3G standards	DC-HSPA+, HSPA, HSPA+, UMTS
SIM card type	MicroSIM
4G bands supported	800, 900, 1800, 2100, 2600 MHz
GSM bands supported	850, 900, 1800, 1900 MHz
UMTS bands supported	900, 2100 MHz
Supported network protocols	IPv4, IPv6
Certification	CE, RoHS
Windows operating systems supported	Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Package type	Box
Package depth	223 mm
Package width	307 mm
Package height	70 mm
Package weight	670 g
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
WLAN data transfer rate (first band)	450 Mbit/s
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	141 mm
Width	202 mm
Height	33.6 mm
