TP-Link Archer VR900 User Manual

61
Chapter 11 NAT Forwarding
11. 1. Share Local Resources in the Internet by Virtual
Server
When you build up a server in the local network and want to share it on the Internet,
Virtual Server can realize the service and provide it to the Internet users. At the same
time virtual server can keep the local network safe as other services are still invisible
from the Internet.
Virtual server can be used for setting up public services in your local network, such as
HTTP, FTP, DNS, POP3/SMTP and Telnet. Different service uses different service port.
Port 80 is used in HTTP service, port 21 in FTP service, port 25 in SMTP service and port
110 in POP3 service. Please verify the service port number before the configuration.
share my personal website I’ve built in local network with my
friends through the Internet.
For example, the personal website has been built in my home PC
(192.168.1.100). I hope that my friends in the Internet can visit
my website in some way. The PC is connected to the modem
router with the WAN IP address 218.18.232.154.
Modem Router
WAN: 218.18.232.154
LAN
Home
Personal Website
1. Assign a static IP address to your PC, for example
192.168.1.100.
2. Visit http://tplinkmodem.net, and log in with the password
you set for the modem router.
3. Go to Advanced > NAT Forwarding > Virtual Servers, click
Add.
I want to:
How can I
do that?

TP-Link Archer VR900 Specifications

General

VPN support	PPTP, L2TP, IPSec Passthrough
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
WLAN data transfer rate (second band)	600 Mbit/s
Input current	3.3 A
Input voltage	12 V
Rack mounting	No
Frequency band	2.4 & 5 GHz
Minimum system requirements	Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0\\r Cable / DSL Modem
WLAN data transfer rates supported	600, 1300 Mbit/s
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Data link protocols	IPv4, IPv6
Supported network protocols	ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MER\\IPoE (RFC 1483 Routed), Bridge (RFC1483 Bridge), PVC
Transmit power	0 dBmW
Antennas quantity	3
Antenna connector type	RP-SMA
Antenna gain level (max)	3 dBi
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Product type	Tabletop router
Product color	White
Mac operating systems supported	macOS
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 98SE, Windows NT, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Output current	2.5 A
Power source type	AC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Certification	CE, RCM, RoHS
Cables included	DSL, LAN (RJ-45), Phone (RJ-11)
WAN connection type	RJ-45
3G	-
Package depth	240 mm
Package width	318 mm
Package height	71 mm
Package weight	1270 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	163.7 mm
Width	215.7 mm
Height	38.9 mm
Weight	- g
