Typical topology in FIT mode:
Figure 2-1 Typical Topology in FIT Mode
NOTE:
The IP address of the wireless
controller must be reachable for the CAPs in the
network.
FAT Mode
In FAT mode, you can log in to AP’s webpage to manage the AP alone. The FAT mode is
used in a small wireless network.
CAP
Wi
r
eless C
ontr
oller
Manangement Host
Clients
CAP
CAP
S
wi
tch
Rou
t
er
In
ternet
