Chapter 1 Introduction
1.1 Overview of the EAP
EAP series products provide wireless coverage solutions for small-medium business. They can
either work independently as standalone APs or be centrally managed by the EAP Controller
software, providing a flexible, richly-functional but easily-configured enterprise-grade wireless
network for small and medium business.
“Celling lamp” appearance and easily mounting design with chassis make EAP easy to be
installed on a wall or ceiling and blend in with most interior decorations.
EAP320/EAP330 can be powered via a PSE* device or the provided power adapter.
With the built-in dual-band antennas module, EAP320/EAP330 operate at both 2.4GHz and 5GHz,
and apply 802.11ac standards and MIMO technology, allowing packet transmission at up to
1200Mbps/1900Mbps.
*PSE: Power Sourcing Equipment, a device (switch or hub for instance) that will provide power
in a PoE setup.
1.2 Hardware Overview
1.2.1 LED
EAP320 and EAP330 have the same LED status and corresponding indications.
Figure 1-1 Top View of the EAP
3
