6
Chapter 1
Get to Know About Your Router
1. 2. 2. Back Panel
The following parts are located on the back panel.
Some Common Buttons and Ports Explanation
Item Description
10Gbps LAN1 Port For connecting your PC or other wired devices to the router.
2.5Gbps LAN2/3/4 Port For connecting your PC or other wired devices to the router.
10Gbps Ethernet
10Gbps SFP+
Combo WAN Port
For connecting to a DSL/Cable modem, or an Ethernet jack.
Phone Port For connecting your analog phone to the VoIP router.
USB Port For connecting to a USB storage device.
Power Port For connecting the router to a power socket via the provided power adapter.
Power On/Off Button Press this button to power on or off the router.
Reset Button
Press and hold the button until all LEDs turn on to reset the router to its
factory default settings.
