TP-Link kasa smart KS205 - Step 1: Turn Off Power and Remove the Wallplate; Step 2: Disconnect wires from the old switch; Step 3: Connect the Wires

5
Step 1. Turn O Power and Remove the Wallplate
Turn o the circuit breaker. Then remove the old wallplate of the wall
switch and label the wires.
Step 3. Connect the Wires
Use the labels and wire nuts to connect the wires to the smart switch as
shown below. You can distinguish Ground and Neutral lines by their colors.
Note: No need to distinguish between Line and Load wires.
3
Wire Your Smart Switch
Step 2. Disconnect wires from the old switch
Gently pull the switch out and disconnect wires from the old switch.
MISE EN GARDE
Risque d'électrocution - Haute tension: débranchez l'alimentation électrique au niveau du disjoncteur avant l'utiliser.
CAUTION
Risk of Electric Shocks - High Voltage - Disconnect power supply at the circuit breaker before servicing.
