TP-Link RE330 User Manual

37
Chapter 6 Use Your Extender as an Access Point
The extender can work as an access point, transforming your existing wired network to
a wireless one.
6. 1. Set Up the Extender as an Access Point
1. Visit http://tplinkrepeater.net, and log in with your TP-Link ID or the password you set
for the extender.
2. Click Change Mode in the top right corner of the page. Select Access Point Mode and
click OK. The extender will reboot and switch to Access Point mode.
3. After rebooting, connect to the extender’s network TP-Link_Extender or TP-Link_
Extender_5GHz.
4. Visit http://tplinkrepeater.net, and log in with your TP-Link ID or the password you set
for the extender.
5. Go to Settings > Quick Setup to configure your extender.
1 ) Customize your wireless SSID and password and click NEXT.
Downloaded from ManualsNet.com search engine

TP-Link RE330 Specifications

General

Type	Network repeater
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Antenna type	Internal
Antennas quantity	2
Wi-Fi	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN (RJ-45) ports	1
Product color	White
Quantity per pack	1 pc(s)
Power consumption (typical)	9.5 W
Package type	Box
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	35 mm
Width	69.5 mm
Height	124.1 mm
