TP-Link RE330 User Manual

42
Chapter 7 Manage Your Extender
7. 1. Set System Time
The System Time of the extender will be used for time-based function such as the
Power Schedule function. If you have enabled the Daylight Saving Time feature, the
system time will be synchronized with the daylight saving time you configure.
1. Visit http://tplinkrepeater.net, and log in with your TP-Link ID or the password you set
for the extender.
2. Go to Settings > System Tools > Time Settings.
• To get system time:
1. Select your local Time Zone from the drop-down list.
2. Click SAVE .
• To set up Daylight Saving Time:
1. Enable Daylight Saving Time.
2. Select the Start and End date and time of the daylight saving time at your local time
zone.
3. Click SAVE .
Downloaded from ManualsNet.com search engine

TP-Link RE330 Specifications

General

Type	Network repeater
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Antenna type	Internal
Antennas quantity	2
Wi-Fi	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN (RJ-45) ports	1
Product color	White
Quantity per pack	1 pc(s)
Power consumption (typical)	9.5 W
Package type	Box
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	35 mm
Width	69.5 mm
Height	124.1 mm
