TP-Link RE330 User Manual

6
Chapter 2 Set Up Internet Connection
2. 1. Power on the Extender
Plug the extender into an electrical outlet next to your router, and then wait until the
Power LED turns solid on.
Power LED: Solid On
Note:
1. Image may differ from your actual product.
2. The operating temperature should be between 0°C and 40°C (32°F - 104°F).
3. For safety, only plug the extender in upright directions as shown below.
2. 2. Set Up the Extender
There are three ways to set up the extender: via the TP-Link Tether app, via a web
browser, or via the WPS button.
2. 2. 1. Method 1: Via the TP-Link Tether App
1. Launch the Apple App Store or Google Play Store and search TP-Link Tether or simply
scan the QR code to download and install the app.
OR
2. Launch the Tether app and log in with your TP-Link ID.
Note: If you don’t have a TP-Link ID, create one first.
Downloaded from ManualsNet.com search engine

TP-Link RE330 Specifications

General

Type	Network repeater
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Antenna type	Internal
Antennas quantity	2
Wi-Fi	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology	10/100Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN (RJ-45) ports	1
Product color	White
Quantity per pack	1 pc(s)
Power consumption (typical)	9.5 W
Package type	Box
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	35 mm
Width	69.5 mm
Height	124.1 mm
