TP-Link TD-W8950ND - Appendix C: Specifications

TD-W8950ND 150Mbps Wireless N ADSL2+ Modem Router User Guide
Appendix C: Specifications
General
Standards
ANSI T1.413, ITU G.992.1, ITU G.992.2, ITU G.992.3, ITU G.992.5,
IEEE 802.3, IEEE 802.3u, IEEE 802.11b , IEEE 802.11g , 802.11n
Protocols TCP/IP, IPoA , PPPoA , PPPoE, SNTP, HTTP, DHCP, ICMP, NAT
LAN Ports:
Four 10/100M Auto-Negotiation RJ45 ports（Auto MDI/MDIX)
Ports
Line Port: One RJ11 port
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Cabling Type
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
(LAN1-4), (WLAN), (ADSL)
LED
(Power), (Internet), (WPS)
Safety & Emissions FCC, CE
Wireless
Frequency Band 2.4~2.4835GHz
Radio Data Rate
11n: up to 150Mbps（Automatic）
11g: 54/48/36/24/18/12/9/6Mbps（Automatic）
11b: 11/5.5/2/1Mbps（Automatic）
Frequency Expansion DSSS(Direct Sequence Spread Spectrum)
Modulation DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM
Security WEP/WPA/WPA2/WPA2-PSK/WPA-PSK
Sensitivity @PER
130M: -64dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
Environmental and Physical
Operating: 0℃~40℃ (32℉~104℉)
Temperature
Storage: -40℃~70℃(-40℉~158℉)
Operating: 10% ~ 90% RH, Non-condensing
Humidity
Storage: 5% ~ 90% RH, Non-condensing
95
