TP-Link TL-CPE200 - Top View

The white fan-shaped area is the signal coverage of the CPE.
The horizontal beam width of CPE is shown in the following table:
,
As shown below
top view
And combined with CPE equipment
,
Make sure the receiving device is
When installing the CPE device, please adjust its front panel
to face the cover. You can use Google Maps and
the horizontal lobe width to roughly determine the direction of the CPE.
,
Tools such as GPS
shenzhen
• direction
TL-CPE200 TL-CPE500
horizontal lobe width
65° 45°
04
model
A
B
sight range
horizontal lobe width
