2.1.8. Squawk Ident (ID, SPI)
On request of the air traffic control, push the ID button (when not in the STBY mode).
Transmission of the ID signal will last for 18 seconds and “IDT” is displayed above the
mode and left side of the Flight ID.
2.1.9. Flight / Ground Indication
Aircrafts with AIR/GROUND switches display “FLY” (Flight) or “GND” (Ground) in the
lower right corner.
This function must be activated in the set-up procedure (see chap. 3.1.4.2).
When this function is not activated, there are no indications on the display and modes
must be manually selected in accordance with chapter 2.1.6.
