7. Technical Data
7.1. General
Designation
Authorization EASA.21O.XXXXXXX
Certification
ETSO-C112d / TSO-C112d
ETSO-C88a / TSO-C88a
ETSO-C166b / TSO-C166b
Compliance
RTCA DO-181E /. ED-73E / Level 2els,Class 1
RTCA DO-178C/ ED-12C Level D
RTCA DO-254 / ED80 Level C
RTCA DO-160G / ED-14G
RTCA DO-260B / ED102A Class B1S
SAE AS8003
FCC ID: 2ANFFKTX2-S
Dimensions KTX2 63 x 62 x 149 (2.48” x 2.44” x 5.86”) pure housing
Weight KTX2 0.381 kg
Mounting KTX2: cut-out Ø 57 mm (2¼”)
Temperature ranges:
Operation
Storage
-20 °C to +55 °C
-55 °C to +85 °C
MAX. flight level 30 000ft
Vibration DO-160G, Cat. S, Vibration Curve M
Humidity RTCA DO-160G, Cat. A
Shock
6G operation
20G crash safety
RTCA DO-160F ENV.
CAT.
[C4Z]CAB[SM]XXXXXXZ[BBB][AC]TTB[B2F2]XXAX
Power supply
Power consumption
9 VDC to 33VDC (test @ 12VDC)
• depending on the No of requests = 0.2 to 1.0A
• Illumination 0.02A
Fuse External fuse required: 3A, slow-blow
Compass security distance 300 mm
Figure 10: Technical Data
