8.3.3 Index high when
Selection Description Conditions Default
K1 = 1, K2 = 1
Parameter:
• K1 leading
direction of rotation
clockwise, with view
onto the flange side
X
K1 = 1, K2 = 0
K1 = 0, K2 = 1
K1 = 0, K2 = 0
