Calibration
Calibrating the detergent mixture of the Cleaning System
Detergent is automatically mixed with the cold water,
in a pre-set mixture, at the factory, of 2 %.
If an alternatively calibration is needed follow the instructions
below to achieve a mixture of 2 % or what is recommended
by your detergent supplier.
To calibrate the mixing setting screw (17) placed on the injector
inside the panel, requires a thin screwdriver, a measuring cup
with a capacity of at least 20 cl, and a bucket with at least 10L
capacity.
- Remove the panel cover.
- Empty the detergent bottle by loosening the hose from the
injector. When empty, connect the hose to the injector again.
- Fill the measuring cup with 20 cl concentrated detergent, open
the detergent bottle lid (18) and pour it into the bottle.
- Place the empty 10L bucket in the tub and hold the cleaning spray
handle (15) with yellow hose over the bucket for filling.
- Open the cleaning safety valve (13) to a fully open position
and spray into the bucket.
- Observe level when bucket fills, while bottle empties. Bucket should
reach 10L mark at the same time as the bottle empties. If bucket
fills first, turn the detergent mixing setting screw (17) on injector
slightly counterclockwise, using the screwdriver. If bottle empties first,
turn the detergent mixing setting screw (17) slightly clockwise.
- Repeat the steps until the injector is calibrated to required mixture.
- Close cleaning safety valve (13) and return the cleaning
handle (15) to the bracket (16) on side of the panel.
- Attach the panel cover.
