TR 900 - Features and Controls: TR 900 A; TR 900 A Control Overview; Component Labels TR 900 A

Hygiene Equipment
Designed for People
19
Features and controls
Features and controls for TR 900A & TR 900A-SS, -C, CW
1
Control buttons, height
adjustment UP/DOWN
2
Thermostatic mixer
3
Digital
T
hermometer
C°
Digital
T
hermometer F° (USA)
4
Tub filling button ON/OFF
5
Bathtub filling spout
6
Overflow drainage
6
Drainage control knob open/close
8
Adjustable footrest
9
Shower button ON/OFF
10
Patient shower hose, White
11
Patient shower handle
12
Bracket for shower handle
13
Cleaning Safety valve
open/close
14
Cleaning hose, Yellow
15
Cleaning handle
16
Bracket for Cleaning handle
17
Setting screw Cleaning injector
(inside the panel)
18
Cleaning detergent filling
19
Cleaning adaptor for Whirlpool
20
Whirlpool ON/OFF button
21
Whirlpool jet (adjustable)
22
Whirlpool air control
23
Whirlpool inlet safety screen
1
2
3
4
9
5
8
22
21
23
8
6
20
1
