TracVision M3 User’s Guide
72
Appendix C - Programming User-Defined Satellites
4. Type the following @SATCONFIG command then
press Enter:
@SATCONFIG,X,E,F,G,H,I,J,K
5. Repeat Step 4 for each polarization/band:
If your selected satellite does not have information for
one or more of these transponder categories, you can
enter the following defaults instead:
6. Type @DEBUGOFF then press Enter.
7. Type ZAP then press Enter. The antenna restarts. Wait
one minute for system startup.
8. Follow the steps in “Selecting Satellites to Track” on
page 27 to select your new USER A or USER B satellite.
Field Description
X User-defined satellite stored in antenna library
(996W = User A; 997W = User B)
E Frequency, MHz (00000 or 10700-12700)
F Symbol rate, kilosymbols per second (10000-45000)
G FEC code (12, 23, 34, 56, 67, or 78)
H Network ID, hexadecimal (0x####)
I Polarization (V = vertical; H = horizontal)
J LNB down conversion frequency
(L = low; H = high; G = Latin America; S = Sinosat)
K Decoding type (1 = DSS-A; 2 = DSS-B; 3 = DVB)
• Vertical High
•Vertical Low
• Horizontal High
• Horizontal Low
Transponder Data Default Value
Frequency 00000
Symbol rate 27500
FEC code Same value as other transponders
with valid data
Network ID 0x0000
