TracVision M3 User’s Guide
73
Appendix C - Programming User-Defined Satellites
Example
The following is an example of programming the fictional “YOURSAT
101” as the USER A user-defined satellite.
YOURSAT 101 at 7ºW, DVB decoder, linear polarization
Based on the above information, you would enter the following
commands into the antenna via your HyperTerminal connection:
HALT
SATCONFIG,996W,7,W,3,L
@DEBUGON
@SATCONFIG,996W,11966,27500,34,0x0800,H,H,3
@SATCONFIG,996W,11823,27500,34,0x0800,V,H,3
@SATCONFIG,996W,00000,27500,34,0x0000,V,L,3
@SATCONFIG,996W,00000,27500,34,0x0000,H,L,3
@DEBUGOFF
ZAP
Transponder Data Value
Horizontal High
Frequency 11.966 GHz
Symbol rate 27500
FEC code 3/4
Network ID 2048 (dec) = 0x0800
Vertical High
Frequency 11.823 GHz
Symbol rate 27500
FEC code 3/4
Network ID 2048 (dec) = 0x0800
Vertical Low
No data listed
Horizontal Low
No data listed
