• Remove the A pillar side
trim and disconnect the
speaker connector
shown.
• Drop the extended wire
from the beacons pickup
into the cab area and
feed along the headlining
to the A pillar.
• Solder the connection
and insulate firstly with
self amalgamating tape
then cover with PVC
tape.
Page 21 of 27
Beacon Cable route
The AA Signs– Company Confidential
Version 1.0
Trakm8 Install Ford Transit
1
2
3
