Trakm8 T8 - Main Trakm8 Unit Installation Location

• The main Trakm8 TCU is
located in the driver side
glove box as shown with
the label facing towards
you.
• Secure the unit with 2
self tapping screws.
• Mount the unit EXACTLY
as shown. The unit has an
internal accelerometer so
secure mounting of the unit
is important.
Page 25 of 27
Main Trakm8 unit
location
