Dimensions and Weights
18 CLCH-SVX009J-EN
Fans
Motors
Table 4. Fan weights (pounds)
Unit
Size
Supply Fan
FC Fan
(a)
Supply Fan
DDP Fan(a)
Return Fan
Motorized
Impeller
(b)
Supply Fan
Motorized
Impeller(b)
Fan (Std TSP)
Supply Fan
Motorized
Impeller(b) Fan
(High TSP)
Indoor Return Fan
Motorized
Impeller(b)
3 30.71 60.63 57.00 30.00 60.00 30.00
6 47.09 96.03 57.00 n/a 87.00 57.00
8 69.21 110.09 98.00 87.00 120.50 100.00
10 83.02 149.12 98.00 n/a 128.00 100.00
12 97.90 158.25 98.00 128.00 241.00 125.00
14 110.46 164.44 125.00 161.00 241.00 160.00
17 133.09 172.89 160.00 256.00 241.00 125.00
21 155.81 290.14 196.00 n/a 256.00 125.00
25 168.83 304.07 196.00 256.00 n/a 250.00
30 208.34 317.00 250.00 322.00 n/a 322.00
(a)Add motor weight to get total weight of the supply fan.
(b)Includes the weight of both the fan and motor.
Table 5. Housed and direct-drive fan motor weights (pounds)
Motor HP Voltage Motor Weight Frame Size
1 200-208, 230/460, 575 38 143
1.5 200-208, 230/460, 575 37 145
2 200-208, 230/460, 575 43 145
3 200-208, 230/460, 575 71 182
3 (3600 rpm, size-3) 200-208, 230/460, 575 89 182
5 200-208, 230/460, 575 82 184
7.5 200-208, 230/460, 575 91 213
10 200-208, 230/460, 575 127 215
15 200-208, 230/460, 575 217 254
