Dimensions and Weights
CLCH-SVX009J-EN 19
Controls
All controls boxes and starters weigh 15 pounds.
Table 6. VFD Weights (pounds) and line input
HP Type FLA RPM
VFD (single Fan) VFD (dual Fan)
Line Input Weight Line Input Weight
1
200 V / 60 Hz / 3 PH 3.50 1800 4.20 10
230 V / 60 Hz / 3 PH 3.00 1800 4.20 10
460 V / 60 Hz / 3 PH 1.50 1800 2.10 10
575 V / 60 Hz / 3 PH 1.20 1800 3.90 20
1.5
200 V / 60 Hz / 3 PH 5.10 1800 6.80 10
230 V / 60 Hz / 3 PH 4.40 1800 6.80 10
460 V / 60 Hz / 3 PH 3.00 1800 3.40 10
575 V / 60 Hz / 3 PH 1.80 1800 3.90 20
2
200 V / 60 Hz / 3 PH 6.50 1800 6.80 10
230 V / 60 Hz / 3 PH 5.80 1800 6.80 10
460 V / 60 Hz / 3 PH 2.90 1800 3.40 10
575 V / 60 Hz / 3 PH 2.40 1800 3.90 20
3
200 V / 60 Hz / 3 PH 9.70 1800 15.20 15 22.00 27
230 V / 60 Hz / 3 PH 8.60 1800 15.20 15 22.00 27
460 V / 60 Hz / 3 PH 4.20 1800 4.80 12 11.00 20
575 V / 60 Hz / 3 PH 3.30 1800 3.90 20 9.00 25
5
200 V / 60 Hz / 3 PH 15.70 1800 22.00 22 42.00 31
230 V / 60 Hz / 3 PH 13.60 1800 22.00 22 42.00 31
460 V / 60 Hz / 3 PH 6.70 1800 8.20 12 14.00 20
575 V / 60 Hz / 3 PH 5.30 1800 6.10 20 11.00 25
7.5
200 V / 60 Hz / 3 PH 22.40 1800 28.00 22 59.40 64
230 V / 60 Hz / 3 PH 19.40 1800 28.00 22 59.40 64
460 V / 60 Hz / 3 PH 9.40 1800 11.00 15 21.00 27
575 V / 60 Hz / 3 PH 7.60 1800 9.00 20 18.00 37
10
200 V / 60 Hz / 3 PH 29.50 1800 42.00 26 59.40 64
230 V / 60 Hz / 3 PH 25.20 1800 42.00 26 59.40 64
460 V / 60 Hz / 3 PH 12.50 1800 14.00 15 27.00 27
575 V / 60 Hz / 3 PH 10.00 1800 11.00 20 22.00 37
15
200 V / 60 Hz / 3 PH 43.40 1800 59.40 59
230 V / 60 Hz / 3 PH 37.80 1800 59.40 59
460 V / 60 Hz / 3 PH 18.50 1800 21.00 22 40.00 31
575 V / 60 Hz / 3 PH 14.80 1800 18.00 20 34.00 64
