Trane Technologies MCW Series - Self-diagnostic Codes; Error Code Explanations

MS-SVU50A-TH16
Self-diagnostic Codes
MYWE09-24GB5
TRANE Thailand
30th - 31st Floor, Vanit Building II
1126/2 New Petchburi Road, Makkasan
Rachthevee, Bangkok 10400 Thailand
Tel: +66 (0) 2761 1111
Amair Limited
999/1 Moo 9, Bangna-Trad Road Km.19
Bang Chalong, Bangplee, Samutprakan 10540
Tel: +66 (0) 2769 2222 FAX: +66 (0) 2769 2254
Literature Order Number: MS-SVU50A-TH
Date: December 2016
Supersedes: February 2016
Stocking Location: Bangkok,Thailand
Trane has a policy of continuous product and product data improvement
and reserves the right to change design and specications without notice.
Error Detail Possible Cause Solution
E1 High Pressure Cut Off
• High pressure incurred while operation • Check heat exchanger or high pressure SW is broken
• Too much refrigerant liquid • Check level of refrigerant liquid
E2 Ice Preventor Cut Off
• Less refrigerant liquid • Check tubes’ leakage, rell the refrigerant liquid
• Dirty coil at FCU • Clean coil at FCU and the lter
E4 High Exhaust Temp. Cut Off
• Less refrigerant liquid, the system is clog • Check level of refrigerant liquid, check capillary tube
• Temp. in discharge tube ≥ 110 ˚C • Check heat exchanger and the condensor fan
E5 Overcurrent Error • Power Source Failure-the preventor works • Check main power, check heat exchanger
E6 Communication Error
• Failed signal sending between FCU &
CDU
• Check signal wire, check the controller board
E8 High CDU Ambient • Temp. at CDU ≥ 53 ˚C • Check the heat exchanger
H3 Overcurrent Preventor,
Compressor Cut Off
• Overcurrent at the compressor • Check discharge temp. ≥ 110 ˚C, check current at the
compressor
H6 Malfunctioned FCU Motor
• Broken motor
• Failed sending signal from PCB
• Check PCB and wires, check Motor & its swirl direction
F1 FCU Room Sensor Error • FCU can’t measure room temp. • Check sensor & cable at PCB
F2 FCU Tube Sensor Error • FCU can’t measure refrigerant tube temp. • Check sensor & cable at PCB
F3 CDU Ambient Temp. Error • CDU can’t measure ambient temp. • Check sensor & cable at PCB
F4 CDU Tube Sensor Error • CDU can’t measure refrigerant tube temp. • Check sensor & cable at PCB
F5 CDU Exhaust Temp. Error • CDU can’t measure coil temp. • Check sensor & cable at PCB
PH
High DC bus-bar Pressure
Error
• AC Voltage at L, N > 265VAC • Check main power
• Normal VAC but DC bus-bar < 400VDC • Check electrolytic capacitor, check Board AP1
U5 Abnormal Current Error • Abnormal operation of Board AP1 • Check board AP1, change board AP1
EE EEPROM Error • CDU & FCU stop operation • Change CDU controller board
