Trane 4YCC4030A1070A - Page 6

6
18-EB31D1-1F-EN
Figure 2. 4YCC4024–4036
BA C
4YCC4024 (060)
4YCC4030 (070)
4YCC4036 (070)
4YCC4036 (090)
Height mm/in
Flu Hood w/brkt
mm/in
Approx. Corner Weight - kg / lbs
D W1 W2 W3 W4
Shipping
Weight
kg/lbs
Total Unit
Weight
kg/lbs
Center of Gravity mm/in
898.53 [35-3/8]
898.53 [35-3/8]
949.33 [37-3/8]
949.53 [37-3/8]
157.16 [6-3/16]
157.16 [6-3/16]
157.16 [6-3/16]
58.3 [129]
61.3 [135]
61.1 [134]
61.7 [136]
36.8 [81]
38.7 [85]
38.3 [84]
38.9 [86]
26.1 [58]
27.5 [61]
27.1 [60]
27.7 [61]
41.0 [90]
43.1 [95]
43.2 [95]
43.7 [96]
196.1 [432]
204.8 [451]
203.4 [438]
205.7 [453]
479.8 [18.9]162.4 [358]
171.1 [377]
169.7 [374]
172.0 [379]
406.5 [16.0]
414.3 [16.3]
414.3 [16.3]
527.8 [20.8]
594.1 [23.4]
697.6 [27.5]
697.6 [27.5]
157.16 [6-3/16]
SStteepp 22 —— DDeetteerrmmiinnee UUnniitt CClleeaarraanncceess
