5 GAM5-SF-1P-EN
AIRFLOW PERFORMANCE
GAM5B0B30M21SB, GAM5B0B30M21EA
EXTERNAL STATIC
(in w.g)
AIRFLOW (CFM)
Speed Taps - 230 VOLTS Speed Taps - 208 VOLTS
5 4 † 3 2 1 5 4 † 3 2 1
0 1282 1150 979 856 678 1279 1146 976 853 675
0.1 1238 1094 931 797 482 1232 1088 925 791 476
0.2 1186 1047 863 725 285 1177 1039 854 716 276
0.3 1141 986 803 647 88 1130 975 791 636 77
0.4 1091 935 721 555 - 1076 921 707 540 -
0.5 1033 866 649 461 - 1016 849 632 444 -
0.6 977 799 554 388 - 958 779 534 369 -
0.7 914 732 490 318 - 892 710 468 296 -
0.8 846 646 429 - - 821 621 404 - -
0.9 771 587 376 - - 743 560 348 - -
NOTES:
1. Values are with wet coil and without filters.
2. Contact your particular filter manufacturer for pressure drop data.
3. Electric heater pressure drop is negligible and is included within the airflow data.
4. Tap 1 is an continuous fan speed tap for single stage systems. Airflow adjustment is required for 2 stage systems.
See Airflow adjustment section.
5. † Factory Setting
Note: Heating and cooling speeds are the same, factory
set at Speed Tap #4.
Note: A “G” only signal from the comfort control will run
the blower at a lower speed, factory set at Speed Tap #1.
See the Sequence of Operation for additional information.
Note: Speed Tap 1 is NOT used for two stage systems.
Two stage systems will require an airflow adjustment.
GAM5B0B30M21SB, GAM5B0B30M21EA MINIMUM HEATER AIRFLOW CFM
Heater Minimum Air Speed Tap
Without HP With HP
BAYEAAC04BK1
BAYEAAC04LG1
Tap 2 Tap 3
BAYEAAC05BK1
BAYEAAC05LG1
Tap 2 Tap 3
BAYEAAC08BK1
BAYEAAC08LG1
Tap 3 Tap 4
BAYEAAC10BK1
BAYEAAC10LG1
Tap 3 Tap 4
BAYEAAC10LG3 Tap 3 ① Tap 4 ①
BAYEABC15BK1 Tap 4 Tap 5
BAYEABC15LG3 Tap 4 Tap 5
BAYEABC20BK1 - -
BAYEACC25BK1 - -
① 208 V not approved for upflow installations
To Next Page
